EGE Elektronik - Contrôleurs de débit - P11097 - LN 520 GA
Reference : LN 520 GA
Marque : EGE Elektronik
Prix unitaire
- Prix HT
238.97 €
Prix TTC286.76 € - QuantitéPrix unitaire HT3231.801€5227.021€
-
Quantité minimale : 1
- Quantité :
-
Description
Plug-in sensor for air flow monitoring Gaseous media Cylindrical smooth design Air flow monitoring in exhaust systems Flow monitoring for fans Filter state monitoring Flow monitoring in air cooling circuits
| Product ID | P11097 |
| Accessories (in scope of delivery) | plastic flange ø20 (Z01106), screwdriver |
| Output function | non linear |
| Protection [EN 60529] | IP 67 |
| Material housing | PBT |
| Detection range air | 0.5 ... 15 m/s |
| Medium temperature | -20 ... 70 °C |
| Current consumption max. | 100 mA |
| Electrical connection | 2 m PVC-cable 3x0.5 mm² |
| Supply voltage | 24 VDC +/- 20 % |
| Material sensor touched by medium | PBT, PUR, AL2O3 |
| Reverse polarity protection | ✓ |
| Reaction time typ. | 3 |
| Ambient temperature | -20 ... 70 °C |
| Medium | air, non-explosive gas |
| Process connection | Ø 20 mm |
| Temperature gradient gaseous media | 200 K/min |
| Output | analog output 4…20 mA |
| Note | probe with longer cable available on request |
| Start-up time | 20 ... 40 s |
| Load RL | 200 ... 500 Ω |
| TYPE | LN 520 GA |
