EGE Elektronik - Contrôleurs de débit - P11348 - SDN 552/5 GAPP
Livraison gratuite
Reference : SDN 552/5 GAPP
Marque : EGE Elektronik
Prix unitaire
- Prix HT
727,76 €
Prix TTC873,31 € - QuantitéPrix unitaire HT3705,927€5691,372€
-
Quantité minimale : 1
-
Quantité :
-
Description
7 segment flow rate indication Analog output and switching output PNP NO/NC Working range 50...1000 ml/min Flow and temperature monitoring of water
| Product ID | P11348 |
| Protection [EN 60529] | IP 65 |
| Material housing | PBT |
| Compressive strength | 10 bar |
| Temperature monitoring | 0 ... 60 °C |
| Medium temperature | 0 ... 60 °C |
| Electrical connection | M12 connector |
| Material sensor touched by medium | FPM, stainless steel AISI 316 Ti |
| Accessories | connecting cable SLG, SLW, mounting plate |
| Reverse polarity protection | ✓ |
| Reaction time typ. | 1 ... 8 s |
| Ambient temperature | 0 ... 60 °C |
| Process connection | G1/4 |
| Output | switching output, analog output 4…20 mA, linear |
| Load RL | 200 ... 500 Ω |
| TYPE | SDN 552/5 GAPP |
| Switching current max. | 200 mA (20 °C) |
| Output function | PNP-NO / NC |
| Inner diameter d | 3.6 mm |
| Current consumption max. | 100 mA |
| Supply voltage | 24 VDC +/- 10 % |
| Detection range ml/min | 50 ... 1000 ml/min |
| Working range | 50 ... 1000 ml/min |
| Medium | Water |
| Programmable functions | switching point, hysteresis, time on/off delay, adjustable to reference, averaging, access code, NC/NO, switch on delay |
| Display | 7-segment / 3 digits |
