EGE Elektronik - Détecteurs de proximité - P31282 - IGMT 02 GSP
Reference : IGMT 02 GSP
Marque : EGE Elektronik
Prix unitaire
- Prix HT
126.72 €
Prix TTC152.06 € - QuantitéPrix unitaire HT3122.918€5120.384€
-
Quantité minimale : 1
- Quantité :
-
Description
Inductive proximity switches for the extended temperature range up to 120° For use at temperatures from -25° C to 120 ° C Water-tight according to IP 67 Variants with up to 110 mm switching distance For example, position query of the conveyor belt in belt dryers
| Material cap | PBT |
| Product ID | P31282 |
| Switching current max. | 200 mA |
| Output function | PNP-NO |
| Protection [EN 60529] | IP 67 |
| Voltage drop max. | 2 V |
| Material housing | brass-Ni, PBT |
| Material thread | Br-Ni |
| Thread/sleeve | M12x1 |
| Current consumption max. | 4 mA |
| Short circuit proof | yes |
| Electrical connection | 2 m silicone-cable 3x0.34 mm² |
| Operating Distance sn | 2 mm flush |
| Supply voltage | 10...48 VDC |
| Reverse polarity protection | ✓ |
| Switching frequency | 500 Hz |
| Ambient temperature | -25 ... 120 °C |
| Output | switching output |
| EMC-class | A |
| TYPE | IGMT 02 GSP |
| Display | ✓ |
